VAS DWG-14 HF Waveguide

• Frequency response: 500 Hz – 20 kHz
• Designed for dual 1.4" compression drivers
• Elliptical flare geometry for smooth, controlled dispersion
• High-density fiberglass construction for rigidity and stability
• Ideal for mid-top, high-frequency, and compact loudspeaker enclosures
• Suitable for touring systems, installations, and custom builds
• Tested and verified by VAS Audio Germany

* Frequency response shown in the measurement section is made in combination with the VAS HF 1.4N Compression Speaker Driver.

Driver Size:
Dual 1.4" Compression Drivers

Frequency Range:
500 Hz - 20 kHz

Throat Diameter:
1.4" / 38mm

Colour:
Black

Material:
Fiber glass

Dimensions:
L: 32.5 cm
W: 19 cm
D: 18.5 cm
Mounting Depth: 17.5 cm

Mounting Bolt Specifications:
Angled slotted bolt holes, fits up to 6.5mm bolts with a radius of 99mm - 103mm

Mounting Hole Specifications:
8 x 6mm mounting holes with 11mm head recess, 3mm deep

• Line-array style top enclosures
• Point-source PA top enclosures
• Front-loaded mid-high top enclosures
• Horn-loaded mid-high enclosures
• Kick-top / mid-high hybrid enclosures
• Compound horns enclosures
